Scales and weighing systems
Curd crushing, packing and transportation Line set
The line is designed to simplify the ouverturning, crushing, weighing andtransport of finished products to the warehouse.With this equipment you can safely transport and weigh the product, whichsimplifies the work process and saves human resources that are essentialfor the company and use human resources in another essential place.
-
Packing ~ up to 35 Pack / min
-
Power ~ 3,2kW
-
Air pressure in operation ~ 5 Bar
-
Block form tipping ~ 2.5pcs / min
Minced pork packing line
Neroli Met offers to buy a new packing machine.
Which will make work easier in production.
Which will increase the production capacity of minced meat.
Up to 8 cycles per minute
EQUIPMENT BASIC ASSEMBLY INCLUDES:
-
Equipment frame, electricity cabinet, melting jaws, vertical melter support. Made of stainless steel.
-
Roll holder with centring cones.
-
One stainless steel shaping tube for making pillow- shaped packaging (adjustable diameter).
-
Photo sensor for film with printing and encoder for determining packaging length.
-
Vacuum belts for film feeding.
-
Equipment version with tilt for product and packaging safety.
-
Product holding mechanism in front of jaws.
-
Packaging support.
-
Vertical seam melting bar with pneumatic drive.
-
Equipment functions are controlled through PLK Siemens.
-
hoto sensor for working with printed film.
-
Possibility to save up to 99 various programs.
-
Equipment control using a 12.2” touch-sensitive panel.
-
Equipment self-diagnostics.
-
Safety devices correspond to the highest safety standards.
-
Set of essential spare parts.
GENERAL EQUIPMENT DATA:
The equipment is intended for forming packaging from a film roll.
PACKAGING DATA:
width 100–320 mm. • max. packaging volume – 6 litres.
length 80–400 mm. • max. roll width – 700 mm. Film roll diameter – max. 350 mm.
Mechanical speed: Up to 90 cycles per minute.
The actual speed will be specified after tests with the actual product and packaging material
Mobile scales
We manufacture customised universal mobile scales according to customer's needs –
Intended for working at the fish sorting line. Can be used at any output of sorted portions.
This work place can be modified with various conveyor belts for different products and with various conveyor lifting angles, for example, if filling in containers or bags is required. Weight ranges and the weighted product have to be specified before ordering.
Components: Conveyor, scales with fixed weight (as standard equipment) for 15, 20, 25, 30 kg, which is set by a switch, control cabinet.
Box strapping work place
Weighing conveyors
The weighing conveyor was manufactured for weighing gingerbread 8 t per shift
The weighing conveyor is intended for use in the food sector. It is easily adaptable to various products (fish, meat, vegetables, etc.). Minimal product weight deviation. We can manufacture it according to the customer’s requirements.
Installation of additional components is possible. Below you can see a description of the weighing conveyor.
Application:
It can weigh all bulk products with diameter range from 5 mm to 80 mm
Power supply:
3 F, 380 V, 50 Hz. Maximum total power consumption: 1.75 kW
Air supply:
Pressure before regulator 0.6 MPa
Work pressure 0.5 MPa
1 l of air at P = 0.5 MPa » required for preparation of a single portion
Production capacity:
Time for preparation of a single portion » 6 s (depending on the weight)
Maximum weight of one portion is 30 kg (can be increased)
Each scales can be operated separately
Manufacturing:
Delivery period of assembly parts 1 month
Product manufacturing period 1 month
For additional information contact the Information Service
Automation of box packaging
Rebuilding semi-automatic box film wrapping equipment - automatic.
Conveyor for wrapping glazed paper packs
The equipment is intended for paper bags with width from 60–120 mm (wider widths are also possible), depth 40–70 mm and more without feeding conveyor, min. height depends on the bag filling, adding 100 mm for broaching and wrapping, max. height without feeding conveyor up to 350 mm.
Assembly:
Length ~2,500 mm\ Width ~1,000 mm\ Height ~1,500 mm\
Work height 1,150mm
Motors - 2 pcs.
Conveyor belts
Frequency converter – EMERSO UNIDRIVE M200
Optical sensor S51-PA- 2-B01- PK MOQ 10
Sealer HB 5010 Buhnen Klebesystem
Total electric power consumption – 3.5 kWt
New weighing packing line
Parameters - 10 head scales (14 hive scales and 24 hive scales)
Material - Stainless steel AISI304
Touch screen 7.0
Weighing range 20 - 1000 grams
Accuracy - + - 0.5
Max speed - 60 packages / 1min
Stepper motor
Connection - 220V / 1000W / 50Hz / 10A
IP65
Weight 400kg
